LG Quick Specs

LG quick specs

Expand the product categories below to view products and their specifications

Wall Splits WS Smart Series

Series	Model	Description	Cooling (kW)	Heating (kW)	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps	Refrigerant	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Weight Indoor/Outdoor (kg)
WS Series	WS09TWS	2.6kW Wall Split	2.6	3.2	308 x 837 x 189	545 x 770 x 288	240/1/50	Outdoor	7	R32	6.35 / 9.52	03 / 20	7.5	20	10	09 / 34
WS Series	WS12TWS	3.4kW Wall Split	3.4	4	308 x 837 x 189	545 x 770 x 288	240/1/50	Outdoor	7	R32	6.35 / 9.52	03 / 20	7.5	20	10	09 / 34
WS Series	WS18TWS	4.8kW Wall Split	4.8	5.9	345 x 998 x 210	545 x 770 x 288	240/1/50	Outdoor	9.5	R32	6.35 / 12.70	03 / 20	7.5	20	10	11 / 34
WS Series	WS24TWS	7.1kW Wall Split	7.1	7.7	360 x 1060 x 265	650 x 870 x 330	240/1/50	Outdoor	14	R32	6.35 / 12.70	03 /30	7.5	20	10	12 / 46

Wall Splits WH High Efficiency Series

Series	Model	Description	Cooling (kW)	Heating (kW)	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps	Refrigerant	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Weight Indoor/Outdoor (kg)
WH series	WH09SK-18	2.5kW Deluxe Wall Split	2.5	3.2	345 x 998 x 210	545 x 770 x 288	240/1/50	Outdoor	6.5	R32	6.35 / 9.52	03 / 20	12.5	20	10	12 / 35
WH series	WH12SK-18	3.5kW Deluxe Wall Split	3.5	4	345 x 998 x 210	545 x 770 x 288	240/1/50	Outdoor	6.5	R32	6.35 / 9.52	03 / 20	12.5	20	10	12 / 35
WH series	WH18SL-19	5.0kW Deluxe Wall Split	5	6	360 x 1060 x 265	650 x 870 x 330	240/1/50	Outdoor	12.7	R32	6.35 / 12.70	03 /30	7.5	20	20	16 / 45
WH series	WH24SL-18	7.1kW Deluxe Wall Split	7.1	8	360 x 1060 x 265	800 x 870 x 320	240/1/50	Outdoor	12.7	R32	9.52 / 15.88	03 /30	7.5	20	20	16 / 55
WH series	WH30SR-18	8.5kW Deluxe Wall Split	8.5	9	360 x 1200 x 265	832 x 950 x 330	240/1/50	Outdoor	16	R32	9.52 / 15.88	03 /30	7.5	20	20	18 / 67
WH series	WH34SR-18	9.4kW Deluxe Wall Split	9.4	10.3	360 x 1200 x 265	832 x 950 x 330	240/1/50	Outdoor	16	R32	9.52 / 15.88	03 /30	7.5	20	20	18 /67

Multi Splits

Series	Model	Description	Cooling (kW)	Heating (kW)	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Max Pipe per branch (m)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Weight Indoor/Outdoor (kg)
MS	MS07AH3	2.1kW Wall Mounted	2.1	2.3	316 x 816 x 189	-	240/1/50	Outdoor	0.2	R410A	6.35 / 9.52	25	-	-	-	-	8.9
MS	MS09AH3	2.6kW Wall Mounted	2.6	3.2	316 x 816 x 189	-	240/1/50	Outdoor	0.2	R410A	6.35 / 9.52	25	-	-	-	-	8.9
MS	MS12AH3	3.5kW Wall Mounted	3.5	4	381 x 892 x 249	-	240/1/50	Outdoor	0.2	R410A	6.35 / 9.52	25	-	-	-	-	8.9
MS	MS18AH3	5.3kW Wall Mounted	5.3	6.3	354 x 975 x 209	-	240/1/50	Outdoor	0.4	R410A	6.35 / 12.70	25	-	-	-	-	11.4
MS	MS24AH2	7.0kW Wall Mounted	7	7.5	354 x 975 x 209	-	240/1/50	Outdoor	0.4	R410A	6.35 / 12.70	25	-	-	-	-	12.2
MS	MS24AH3	7.0kW Wall Mounted	7	7.5	354 x 975 x 209	-	240/1/50	Outdoor	0.4	R410A	6.35 / 12.70	25	-	-	-	-	12.2

Brand	Series	Model	Description	Cooling (kW)	Heating (kW)	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Max Pipe per branch (m)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Weight Indoor/Outdoor (kg)
LG	UHxM	UHxM55MA2	5.3kW Multi Outdoor 3 Heads	5.3	6.3	-	655 x 870 x 320	240/1/50	Outdoor	12.2	R410A	6.35 / 9.52	25	50	30	20	7.5 / 15	45
LG	UHxM	UHxM70MA2	7.0kW Multi Outdoor 4 Heads	7	8	-	834 x 950 x 330	240/1/50	Outdoor	12.9	R410A	6.35 / 9.52	25	70	30	20	7.5 / 15	64
LG	UHxM	UHxM90MA1	8.8kW Multi Outdoor 5 Heads	8.8	10.1	-	834 x 950 x 330	240/1/50	Outdoor	16.5	R410A	6.35 / 9.52	25	75	37.5	20	7.5 / 15	64

High Static Ducted

Series	Model	Description	Cooling (kW)	Heating (kW)	Airflow (l/sec) H/M/L	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps (Outdoor)	Max Fuse Amps	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Supply Air Connection H x W (mm)	Return Air Connection H x W (mm):	Weight Indoor/Outdoor (kg)2
High Static Ducted	UHN85B7	8.8kW High Static	8.8 (2.5 - 9.6)	9.4 (2.7 - 11.1)	533	400 x 1320 x 534	834 x 950 x 330	240/1/50	Outdoor	17	25	R32	9.52 / 15.88	05 / 50	10	40	30	287 x 840	317 x 1172	48 / 59
High Static Ducted	UHN100B7	10.5kW High Static	10.5 (3.2 - 13.0)	13.0 (3.4 - 13.7)	700	400 x 1320 x 534	1380 x 950 x 330	240/1/50	Outdoor	29	40	R32	9.52 / 15.88	05 / 85	20	50	30	287 x 840	317 x 1172	48 / 89
High Static Ducted	UHN125B7	12.5kW High Static	12.5 (4.0 - 14.8)	15.0 (4.0 - 16.5)	833	400 x 1320 x 534	1380 x 950 x 330	240/1/50	Outdoor	29	40	R32	9.52 / 15.88	05 / 85	20	50	30	287 x 840	317 x 1172	51 / 89
High Static Ducted	UHN150B7	15.0kW High Static	15.0 (4.8 - 15.8)	17.0 (4.8 - 18.0)	1000	400 x 1320 x 534	1380 x 950 x 330	240/1/50	Outdoor	29	40	R32	9.52 / 15.88	05 / 85	20	50	30	287 x 840	317 x 1172	51 / 89
High Static Ducted	B62AWYN9L6 / U7L6	18.0kW High Static	18.0 (4.8 - 19.8)	20.6 (4.8 - 20.6)	1333	458 x 1563 x 791	1625 x 1090 x 380	415/3/50	Outdoor	24	30	R410A	12.70 / 22.20	75	15	70	30	286 x 1044	392 x 1368	89 / 144
High Static Ducted	B70AWYN9L6 / U7L6	20.0kW High Static	20.0 (8.0 - 22.0)	22.6 (9.0 - 24.9)	1333	458 x 1563 x 791	1625 x 1090 x 380	415/3/50	Outdoor	24	30	R410A	12.70 / 22.20	75	15	70	30	286 x 1044	392 x 1368	89 / 144

Mid Static Ducted

Series	Model	Description	Cooling (kW)	Heating (kW)	Airflow (l/sec) H/M/L	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps (Outdoor)	Max Fuse Amps	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Supply Air Connection H x W (mm)	Return Air Connection H x W (mm):	Weight Indoor/Outdoor (kg)2
Slim Ducted	UMN70M1	6.8kW Mid Static	6.8 (2.7 - 8.0)	7.5 (3.0 - 9.0)	300	270 x 900 x 700	834 x 950 x 330	240/1/50	Outdoor	17	25	R32	9.52 / 15.88	05 / 50	10	40	30	200 x 857	231 x 849	24 / 59
Slim Ducted	UMN85M1	8.0kW Mid Static	8.0 (3.1 - 9.0)	9.0 (3.6 - 10.1)	367	270 x 900 x 700	834 x 950 x 330	240/1/50	Outdoor	17	25	R32	9.52 / 15.88	05 / 50	10	40	30	200 x 857	231 x 849	25 / 59
Slim Ducted	UMN100M2	9.5kW Mid Static	9.5 (3.8 - 12.5)	10.8 (4.3 - 13.4)	533	270 x 1250 x 700	1380 x 950 x 330	240/1/50	Outdoor	17	40	R32	9.52 / 15.88	05 / 85	20	50	30	197 x 1206	230 x 1205	37 / 89
Slim Ducted	UMN125M2	12.3kW Mid Static	12.3 (4.8 - 14.0)	13.5 (5.4 - 15.8)	633	270 x 1250 x 700	1380 x 950 x 330	240/1/50	Outdoor	28	40	R32	9.52 / 15.88	05 / 85	20	50	30	197 x 1206	230 x 1205	37 / 89
Slim Ducted	UMN140M3	13.8kW Mid Static	13.8 (5.4 - 15.7)	15.5 (6.2 - 17.5)	667	360 x 1250 x 700	1380 x 950 x 330	240/1/50	Outdoor	28	40	R32	9.52 / 15.88	05 / 85	20	50	30	291 x 1206	320 x 1205	41 / 89

Bulkhead Ducted

Series	Model	Description	Cooling (kW)	Heating (kW)	Airflow (l/sec) H/M/L	Indoor Dimensions H x W x D (mm)	Outdoor Dimensions H x W x D (mm)	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps (Outdoor)	Max Fuse Amps	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Supply Air Connection H x W (mm)	Return Air Connection H x W (mm):	Weight Indoor/Outdoor (kg)2
Bulkhead	UBN25L5	2.5kW Bulkhead	2.5 (1.5 - 3.2)	3.2 (1.8 - 4.0)	192	190 x 900 x 460	545 x 770 x 288	240/1/50	Outdoor	10	15	R32	6.35 / 9.52	05 / 30	7.5	20	30	148 x 860	155 x 787 (no flange)	18 / 34
Bulkhead	UBN35L5	3.4kW Bulkhead	3.4 (1.5 - 4.7)	4.0 (1.8 - 4.9)	192	190 x 900 x 460	545 x 770 x 288	240/1/50	Outdoor	10	15	R32	6.35 / 9.52	05 / 30	7.5	20	30	148 x 860	155 x 787 (no flange)	18 /34
Bulkhead	UBN50L6	5.0kW Bulkhead	5.0 (2.0 - 5.8)	5.8 (2.3 - 6.7)	250	190 x 1100 x 460	650 x 870 x 330	240/1/50	Outdoor	16	20	R32	6.35 / 9.52	05 / 30	7.5	20	30	148 x 1062	155 x 987 (no flange)	21 / 45

Cassettes

Series	Model	Description	Cooling (kW)	Heating (kW)	Airflow (l/sec) H/M/L	Indoor Dimensions H x W x D (mm):	Outdoor Dimensions H x W x D (mm):	Power Supply (V/Ph/Hz)	Power Supply Connection	Max Amps (Outdoor)	Refrigerant Type	Pipe Sizes (Liquid/Gas mm)	Min/Max Pipe Run (m)	Pre-Charged Run (m)	Add Ref Charge (g/m)	Max Elevation (m)	Weight Indoor/Outdoor (kg)2
UTN	UTN70PB / UU70WR2	6.8kW Cassette	6.8	7.5	283	204 x 840 x 840	834 x 950 x 330	240/1/50	Outdoor	16	R32	9.52 / 15.88	05 / 50	10	40	30	22 / 59
UTN	UTN85PB / UU85WR2	8.0kW Cassette	8	8.9	317	204 x 840 x 840	834 x 950 x 330	240/1/50	Outdoor	17	R32	9.52 / 15.88	05 / 50	10	40	30	22 / 59
UTN	UTN100MA / UU100WR2	9.5kW Cassette	9.5	10.8	458	288 x 840 x 840	1380 x 950 x 330	240/1/50	Outdoor	17	R32	9.52 / 15.88	05 / 85	20	50	30	26 / 89
UTN	UTN125MA / UU125WR2	12.3kW Cassette	12.3	13.5	459	288 x 840 x 840	1380 x 950 x 330	240/1/50	Outdoor	28	R32	9.52 / 15.88	05 / 85	20	50	30	26 / 89
UTN	UTN140MA / UU140WR2	13.6kW Cassette	13.6	15.5	500	288 x 840 x 840	1380 x 950 x 330	240/1/50	Outdoor	28	R32	9.52 / 15.88	05 / 85	20	50	30	26 / 89

Multi V VRF Systems

No Data Available
